Description:

Full 8K@60Hz for Long Distance Transmission

The DP fiber cable is FULL 8K@60Hz for Long distance transmission

4K@165Hz/144Hz HBR3 for long distance. 32.4Gbps bandwidth High Speed, 4-core optical fiber and 8-core copper conductors.

Active DP 1.4 Fiber Optic Cable

The dp cable is one-way transmission. "Source" plug for connecting DP source port, (blu-ray player, PC, ThinkPad, etc). "Display" Plug for connecting DP display device, (HDTV, monitor, projector etc). Plug and play.

Flexible & Application.

The displayport fiber cable is very flexible and thin. OD = 0.189 inch (4.8mm). It can withstand more than 1000+ 90 degree bends lifespan. Universally compatible with graphics cards, like Geforce GTX 980/1080/970/660/680/760/780, Radeon R9 290, ASUS HD 7970 DCII, HD Graphics 4600, etc. Tolerated temperature range 14℉-176℉ (-10℃-80℃).

Supports 8K@60Hz or 4K at 120/60 or 30Hz

Up to 32Gbps

DisplayPort 1.4

HBR 3

Metal Connectors

4 Fibre cores / 8 Copper cores

Cable Outer Diameter 4.8mm

CPR rated (The CPR defines several classes that indicate the impact of cables on the spread of fire)

ECA Rated (Eca cables can safely be installed in buildings that have Basic building fire safety requirements in some regions this class is used for general installs.)

LSZH (Low Smoke Zero Halogen)

This cable must be connected with the Source connector & Display connector connected the correct way round

DisplayPort V1.4 is capable of 8K at 60Hz and is backwardly compatible with all previous displayport connections. This cable is suitable for 4K resolutions at 120 60 or 30Hz as well as older 1080P or 720P displays.
